An Investigation of the Shearing Forces Using Blanked Carbon Steel Sheets

Ahmad Saad Jasim 1 Ali Abbar Khleif 2
1 Department Petroleum Technology, University of Technology, Baghdad- Iraq.
2 Department Production Engineering and Metallurgy, University of Technology, Baghdad- Iraq.
History
  • Received: May 25, 2019
  • Revised: June 10, 2019
  • Accepted: June 19, 2019
  • Available Online: July 21, 2019
DOI

https://doi.org/10.29194/NJES.22020131

Abstract

An important challenge confronted when using blanking to machine sheet metal is the treatment of the shearing force in demand for great strength and heavy stock. One of the methods used to decrease the force wanted is the increase of a punch shear angle. In this work, experiments were conducted to study the effect of shear angle for blank has a diameter (50 mm) on shear force of a low carbon steel sheet (AISI 1008). Low carbon steel is a very common material used in fabrication of sheet metal components, with thickness of (0.5 mm). Tools used in the blanking tests were one traditional flat end punch and four different bevel sheared rooftop punches, which rooftop punches were compared to. and it (0°, 5°, 10°, 15°, 20°) a punches diameter (49.95 mm) by clearance (0.025mm) for each side , with a blanking speed (500mm/min). A special blanking die set is designed and manufactured and was a blank cut by a hydraulic press whose capacity (20 ton). The results showed that the blanking forces of (AISI 1008) low carbon steel metal could be decreased radically with best bevel punch geometry. Using (10°) shear angle at the punch end, the cutting forces decreased up to (90%) compared to the ones of the traditional flat end tool

Keywords

References

  1. Avadhani, S. P., et al, "Design and Analysis of Blanking and Piercing die punch", International Research Journal of Engineering and Technology, Volume: 04 Issue: 05, 2017.
  2. MacIsaac Jr, Jamie D., and Jochen Breitling. "Ultra-High-Speed Blanking Forces". Columbus, Ohio: Ohio State University, 1996.
  3. Boljanovic, Vukota. "Sheet metal forming processes and die design". Industrial Press Inc. New York, United States of America, 2004.
  4. Black, Bruce J. "Workshop processes, practices and materials ".Fifth edition, Routledge, 2015.
  5. Gürün, Hakan, Mustafa Göktaş, and Abdulmecit Güldaş. "Experimental Examination of Effects of Punch Angle and Clearance on Shearing Force and Estimation of Shearing Force Using Fuzzy Logic" ,Transactions of FAMENA 40, no. 3, pp. 19-28, 2016.
  6. Mackensen, A., Golle, M., Golle, R., & Hoffmann, H. Experimental investigation of the cutting force reduction during the blanking operation of AHSS sheet materials. CIRP annals, 59, pp. 283-286, 2010.
  7. Kutuniva, Kari, Jussi A. Karjalainen, and Kari Mäntyjärvi. "Effect of Convex Sheared Punch Geometry on Cutting Force of Ultra-High-Strength Steel", Key Engineering Materials, vol. 504, pp. 1359-1364, 2012.
  8. Subramonian, Soumya, Taylan Altan, Craig Campbell, and Bogdan Ciocirlan. "Determination of forces in high speed blanking using FEM and experiments" Journal of Materials Processing Technology, 213, no. 12, pp. 2184-2190, 2013.
  9. Behrens, Bernd-Arno, Anas Bouguecha, Milan Vucetic, Richard Krimm, Tobias Hasselbusch, and Christian Bonk. "Numerical and experimental determination of cut-edge after blanking of thin steel sheet of DP1000 within use of stress based damage model." Procedia Engineering, 81, pp. 1096-1101, 2014.
  10. Wang, Kai, and Tomasz Wierzbicki. "Experimental and numerical study on the plane-strain blanking process on an AHSS sheet" International Journal of Fracture, 194, no. 1, pp. 19-36, 2015.
  11. Dhoble, Mr Pankaj G., R. R. Deshmukh, and Mr Sushil D. Yeole. "Application of Finite Element Analysis Method to Investigate Effect of Blanking Process Variables on Sheet" International Journal of Engineering Technology Science and Research (IJETSR), Vol. 5, Iss. 4, 2015.
  12. Gürün, Hakan, Mustafa Göktaş, and Abdulmecit Güldaş. "Experimental Examination of Effects of Punch Angle and Clearance on Shearing Force and Estimation of Shearing Force Using Fuzzy Logic" ,Transactions of FAMENA 40, no. 3, pp. 19-28, 2016.
  13. Patil, Aniket N., and V. L. Kadlag. "Blanking Process Optimization using Finite Element Analysis & Taguchi Method" IJSTE - International Journal of Science Technology & Engineering , Volume 2 , Issue 12 , June 2016.
  14. Engin, K. E. and Eyercioglu O. Purpose Oriented Clearance Selection in Blanking Process, European International Journal of Science and Technology, 6, pp. 66-76, 2017.
  15. Engin, Kaan Emre, and Omer Eyercioglu. "The Effect of the Thickness-to-Die Diameter Ratio on the Sheet Metal Blanking Process", Strojniski Vestnik /Journal of Mechanical Engineering, 63, no. 9, 2017.
