Numerical Analysis of the Effect of Scanning Speed on the Temperature Field Distribution for Laser Heat Treatment Applications

Furat I. Hussein Al-Najjar 1
1 Mechatronics Engineering Department, Al-Khwarizmi College of Engineering, University of Baghdad, Baghdad 10071, IRAQ.
History
  • Received: November 26, 2017
  • Revised: December 25, 2017
  • Accepted: January 4, 2018
  • Available Online: April 22, 2018
DOI

https://doi.org/10.29194/NJES21020213

Abstract

One of the unique properties of laser heating applications is its powerful ability for precise pouring of energy on the needed regions in heat treatment applications. The rapid rise in temperature at the irradiated region produces a high temperature gradient, which contributes in phase metallurgical changes, inside the volume of the irradiated material. This article presents a comprehensive numerical work for a model based on experimentally laser heated AISI 1110 steel samples. The numerical investigation is based on the finite element method (FEM) taking in consideration the temperature dependent material properties to predict the temperature distribution within the irradiated material volume.  The finite element analysis (FEA) was carried out using the APDL scripting language (ANSYS Parametric Design Language) that is provided by the commercial code ANSYS. Infrared (IR) thermography technique was used to explore the workpiece surface and to validate the obtained results. The work takes into account the effect of different speeds of the laser beam and pulses overlap on the temperature pattern of the material surface and depth.

Keywords

References

  1. W. M. Steen. "Laser Material Processing" 4th edition. Springer London Dordrecht Heidelberg New York, 2010.
  2. M. Allmen, A. Blatter. “Laser-Beam Interactions with Materials: Physical Principles and Applications” 2nd edition. Springer-Verlag Berlin Heidelberg GmbH, 1998.
  3. J. Dutta Majumdar and I. Manna. “Laser Processing of Materials”. Sadhana, 2003; 28, Parts 3 & 4: 95–562.
  4. Yih-Fong Tzeng. “Effects of operating parameters on surface quality for the pulsed laser welding of zinc-coated steel”. Journal of Materials Processing Technology, Elsevier. 100 (2000) 163-170.
  5. F. Hussein, E. Akman , B. Oztoprak, M. Gunes, O. Gundogdu, E. Kacar, K. Hajim and A. Demir. “Evaluation of PMMA joining to stainless steel 304 using pulsed Nd:YAG laser”, Elsevier. Optics & Laser Technology 49(2013)143–152.
  6. K.A. Mumtaz and N. Hopkinson. “Selective Laser Melting of thin wall parts using pulse shaping”. Journal of Materials Processing Technology, Elsevier. 210 (2010) 279–287.
  7. S. Shuja, B. Yilbas and O. Momin.” Laser heating of a moving slab: Influence of laser intensity parameter and scanning speed on temperature field and melt size”. Optics and Lasers in Engineering, Elsevier. 49(2011)265–272.
  8. A. Kaplan. “Model of the absorption variation during pulsed laser heating applied to welding of electronic Au/Ni-coated Cu-lead frames”. Applied Surface Science 241 (2005) 362–370.
  9. R. Gospavic, M. Sreckovic, V. Popov and Goran Todorovic. “3D modeling of material heating with the laser beam for cylindrical geometry”. Mathematical and Computer Modelling 43 (2006) 620–631.
  10. D. Sowdari and P. Majumdar. “Finite element analysis of laser irradiated metal heating and melting processes”. Optics & Laser Technology 42 (2010) 855–865.
  11. B. Yilbas, S. Shuja and S. Khan. “Laser repetitive pulse heating of tool surface“Optics & Laser Technology 43 (2011) 754–761.
  12. Q. Peng. “An analytical solution for a transient temperature field during laser heating a finite slab” Applied Mathematical Modelling 000 (2015) 1–7.
  13. W. Piekarska, M. Kubiak and Z. Saternus. “Application of Abaqus to analysis of the temperature field in elements heated by moving heat sources”. Archives of foundry engineering volume 10, issue 4/ 2010, 177 – 182.
  14. S. Paul, R. Singh and W. Yan. “Finite Element Simulation of Laser Cladding for Tool Steel Repair”. Lasers Based Manufacturing, the 5th International and 26th All India Manufacturing Technology, Design and Research Conference, AIMTDR 2014.
  15. I. Ivanovi, A. Sedmak, M. Miloš, A. Živkovi and M. Lazi. “Numerical Study of Transient Three-Dimensional Heat Conduction Problem with a Moving Heat Source”. Thermal Science, volume 15, issue 1/2011, 257-266.
  16. J. Yanga, S. Suna, M. Brandtb and W. Yanc. “Experimental investigation and 3D finite element prediction of the heat affected zone during laser assisted machining of Ti6Al4V alloy”. Journal of Materials Processing Technology, Elsevier. 210 (2010) 2215–2222.
  17. N. Shanmugam, G. Buvanashekaran, and K. Sankaranarayanasamy. “Some Studies on Temperature Distribution Modeling of Laser Butt Welding of AISI 304 Stainless Steel Sheets”. International Science Index, Mechanical and Mechatron-ics Engineering Vol:7, No:7, 2013 waset.org/Publication/16444.
  18. Z. Huaa and Xu Jiawena. “Modeling and Experimental Investigation of Laser Drilling with Jet Electrochemical Machining”. Chinese Journal of Aeronautics 23(2010) 454-460.
  19. Kenneth C Mills. “Recommended values of thermophysical properties for selected commercial alloys”. Woodhead Publishing Limited and ASM International, 2002.
  20. F. P. Incropera and D. P. Dewitt. “Fundamentals of Heat and Mass Transfer”, 7th edition. John Wiley & Sons, Inc.
  21. http://www.matweb.com.
  22. E. Kennedy, G. Byrne and D.N. Collins. “A Review of the Use of High Power Diode Lasers in Surface Hardening”. Journal of Materials Processing Technology 155–156 (2004) 1855–1860.
  23. Y.-F. Tzeng. “Process Characterization of Pulsed Nd:YAG Laser Seam Welding”. Advanced Manufacturing Technology, 2000; 16:10 – 18.
