A Comparitive Study of CNC Milling Cutting Path Strategies

Ali Abbar Khleif 1 Majeed Nemat 1 Hasan Nemah Khniefer 1
1 Dept. of Production Engineering and Metallurgy, University of Technology
History
  • Received: October 1, 2016
  • Available Online: January 1, 2017

Abstract

This paper investigates the effect of cutter path used in the milling process on the produced surface roughness using two different tools. The cutting paths which are named as; one directional, zigzag , Morph, overlap spiral and spiral are considered as cutter path strategies. The cutter path strategies greatly influenc the surface finish of the work pieces. The objective of this study is to investigate the best cutting characteristics and effects of cutting path for aluminuim using end mill and ball mill tools. MASTER CAM software has been used in design and producing NC CODE. The results indicate that the raw tool path strategy and flat end mill tool gives minimum roughness value with (0.15µm), while the spiral tool path strategy and ball end mill tool gives minimum roughness value with (0.76µm).

Keywords

References

  1. Monies F.,Rudio W. and Redonnet JM., (2001), “Comparitive study of interference caused by different positions of a conical milling cutter on a ruled surface”, vol.-215(9), pp. 1305-1317.
  2. Chuang J. C. and Yuan S. L., (2002),"Machining potential field control to tool path generation for multi axis sculpture surface machining", vol. 34, pp. 357-371.
  3. Zao C. and Peiquin Y., (2002), "Tool path generation strategy for sculptured surface machining", vol. 127, pp. 369-373.
  4. Kaymakci L., (2008), “Tool path selection strategies for complex sculptured surface machining”, Machining Science and Technology. International Journal.
  5. Amro M. Fikry Y., (2004), “Optimization of machining strategy and process planning of complex geometry”, Ph.D. thesis, McMaster University Hamilton, Ontario.
  6. Ng C., (2012 ), “3-axis and 5-axis machining with stewart platform”, Ph.D. Thesis, Department of Mechanical Engineering National University of Singapore.
  7. Rakesh P., Avadhoot R. and Vijaykumar C., (2013), “Tool path optimization of contouring operation and machining strategies for turbo machinery blades”, International Journal of Engineering Trends and Technology, vol.4, issue5, pp. 1731-1737.
  8. Youngwook P., (2011), “Milling tool-path based on micrography”.
